Jig Saw Blades
Jig Saw Blades
Jig Saw Blades
KW03
SPECIFICATION
Bosch style (T Shank)
ShapeTooth LengthItem No.DescriptionApplication
TPIBosch No.

H.S.S wavy set thickness 1mm
(50mm) 2" KW03-0001 Mild stee l, non-terrous metals,
aluminium up to 2mm, sheet metal
<1mm.
32 T118G

H.S.S wavy set thickness 1mm
(50mm) 2" KW03-0002 Mild steel, non-ferrous metals and
aluminum 1.5-4mm.
24 T118A

H.S.S wavy set thickness 1mm
(50mm) 2" KW03-0003 Mild steel, up to 3mm, non-ferrous
metals and aluminum 3-10mm.
12 T118B

H.S.S wavy set thickness 1mm
(75mm) 3" KW03-0004 Mild steel 3-6mm, non-ferrous
metals, aluminium 3-15mm,
lead and tin up to 20mm.
8 T127D

H.S.S wavy set thickness 1mm
(100mm) 4" KW03-0005 Straight, fine cuts in soft steel 3-6
mm, non-ferrous metal, aluminum,
aluminum alloys 3-10mm.
24 T318A

H.S.S wavy set thickness 1mm
(100mm) 4" KW03-0006 Curve cutting; fine cuts in plastic,
aluminum, non-ferrous metal <
3-10mm, steel < 3-10mm.
12 T318B

ShapeTooth LengthItem No.DescriptionApplication
TPIBosch No.

Bi-metal wavy set thickness 1mm
(50mm) 2" KW03-0006 Straight, fine cuts in soft steel,
non-ferrous metal, sheet metal
< 1.5-4mm.
24 T118AF

Bi-metal ground and
tapered thickness 1.3mm
(75mm) 3" KW03-0107 Quick, fine cuts in hardwood, soft wood
and plywood, blackboard, plastic(incl.
fiberglass reinforced)<30mm.
10 T101BF

Bi-metal ground and
tapered thickness 1.3mm
(75mm) 3" KW03-0109 Splinter-free cuts with down
cutting teeth in hardwood, softwood
and plywood, blackboard, plastic
(incl. fiberglass reinforced)<30mm
10 T101BRF

H.C.S wavy set thickness 1mm
(50mm) 2" KW03-0301 Tight curve cuts, hardwood,
softwood, plywood, chipboard,
plastic and perspex, insulation
material < 20mm.
12 T119BO

H.C.S wavy setting thickness 1.3mm
(120mm) 4-3/42" KW03-0302 Fast cutting blade in wood
< 100mm.
6 T344D

H.C.S wavy set thickness 1mm
(75mm) 3" KW03-0303 Coarse cut in hardwood, softwood,
plastic < 60mm.
9 T111C

H.C.S wavy set thickness 1.3mm
(75mm) 3" KW03-0304 Quick cutting blade in hard and soft
woods, plastic up to 60mm, cutting
depth double lug shank < 40mm.
6 T144D

H.C.S wavy set thickness 1.3mm
(75mm) 3" KW03-0305 Curve cutting blade for hard and
soft woods up to 60mm,
Chipboard < 60mm.
6 T244D

H.C.S ground and tapered
thickness 1.3mm
(75mm) 3" KW03-0306 Clean cutting blade for hard and soft
woods, plywood, blockboard, plastic
< 30mm.
10 T101B

H.C.S ground and tapered
thickness 1.3mm
(75mm) 3" KW03-0307 Splinter-free cutting (down cutting
teeth) in hard and soft woods, plywood,
laminated, chip-boards, plastic up to
30mm.
6 T101D

H.C.S wavy set thickness 1mm
(75mm) 3" KW03-0308 Fast, coarse cutting blade in wood,
plastic < 30mm.
12 T101BR

H.C.S ground and
side set thickness 1.5mm
(75mm) 3" KW03-0309 Curve cutting blade for hard and soft
woods up to 60mm, chipboard < 60mm.
6 T244DR1

H.C.S ground and
tapered thickness 1.5mm
(75mm) 3" KW03-0310 Curve cutting blade for hard and soft
woods up to 60mm, chipboard < 60mm.
7 T244DR1

H.C.S ground and
side set thickness 1.3mm
(75mm) 3" KW03-0311 Quick cutting blade in hard and soft woods,
plastic up to 60mm.
6 T144DR

H.C.S ground and
tapered thickness 1.3mm
(75mm) 3" KW03-0312 Clean parallel cuts in hard wood, softwood,
blockboard, plywood, chipboard, plastic
< 60mm.
8.5 T101B

H.C.S ground and
tapered thickness 1.3mm
(75mm) 3" KW03-0313 Clean cutting blade for hardwood,
soft woods, plywood, blockboard,
plastic < 30mm.
12 T101B

Tungsten carbide coated
(50mm) 2" KW03-0401 Coarse filing effect in abrasive
materials < 15mm.
Grit 30 T130RIFF

Tungsten carbide coated
(50mm) 2" KW03-0402 Coarse filing effect in abrasive
materials < 10mm.
Grit 50 T150RIFF
B & D style (U Shank)
ShapeTooth LengthItem No.DescriptionApplication
TPIBosch No.

H.S.S wavy set thickness 1mm
(66mm) 2-3/5" KW03-1001 Straight, fine cuts in soft steel, non-
ferrous metal, aluminium, aluminium
alloys < 1.5-4mm, acrylic glass < 1.5-3mm.
24 U118A

H.S.S wavy set thickness 1mm
(66mm) 2-3/5" KW03-1002 Straight, fine cut in soft steel, aluminum
, non- ferrous metal < 2.0mm, sheet
metal (saw through wooden support)
< 1mm.
32 U118G

H.S.S wavy set thickness 1mm
(66mm) 2-3/5" KW03-1003 Straight, fine cuts in soft steel < 3-6mm,
non- ferrous metal, aluminium,
aluminium alloys < 3-10mm.
12 U118B

H.S.S wavy set thickness 1mm
(50mm) 2" KW03-1004 Straight, fine cuts in soft steel, non-
ferrous metal, aluminium, aluminium
alloys < 1.5-4mm, acrylic glass < 1.5-3mm.
24 U118A

H.S.S wavy set thickness 1mm
(50mm) 2" KW03-1005 Straight, fine cuts in soft steel < 3-6mm
, non-ferrous metal, aluminium,
aluminium alloys < 3-10mm.
12 U118B

H.S.S wavy set thickness 1.3mm
(75mm) 3" KW03-1006 Straight, fine cuts in soft steel, non-
ferrous metal, aluminium < 10mm,
perspex.
12

H.S.S wavy set thickness 1.3mm
(75mm) 3" KW03-1007 Straight, fine cuts in soft steel, non-
ferrous metal, aluminium < 20mm,
perspex.
10
B & D style (U Shank)
ShapeTooth LengthItem No.DescriptionApplication
TPIBosch No.

Bi-metal ground and side set
thickness 1.3mm
(75mm) 3" KW03-1103 Fast, coarse cuts in hardwood, softwood,
chipboard, blockboard < 60mm.
6 U144DF

Bi-metal ground and side set
thickness 1.3mm
(75mm) 3" KW03-1104 Fast, coarse cuts in hardwood, softwood,
chipboard, blockboard < 60mm.
10 U101BF

H.C.S wavy set thickness 1mm
(50mm) 2" KW03-1300 Hardwood, soft woods, plywood,
chip-boards up to 30mm.
10 U119B

H.S.S wavy set thickness 1mm
(75mm) 3" KW03-1302 Coarse cutting in hardwood, softwood,
plastic < 50mm.
8 U111C

H.S.S wavy set thickness 1mm
(50mm) 2" KW03-1303 Tight curve cuts for hardwood, softwood,
plywood, chipboard, plastic and perspex,
insulation material < 20mm.
12 U19BO

H.S.S wavy set thickness 1mm
(75mm) 3" KW03-1304 Quick cutting blade in hard and soft
woods, plastic < 50mm.
6 U111D

H.C.S ground and side set
thickness 1.3mm
(75mm) 3" KW03-1305 Hard and soft woods, chip-boards up to
60mm, for curved cuts.
6 U144D

H.C.S wavy set thickness 1.3mm
(100mm) 4" KW03-1306 Fast, coarse cutting blade in wood,
plastic < 100mm.
6 U344D

H.C.S ground and tapered
thickness 1.3mm
(75mm) 3" KW03-1307 Hard and soft woods, plywood, chip-
boards up to 20mm clean cutting.
12 U101B

H.C.S ground and tapered
thickness 1.3mm
(75mm) 3" KW03-1310 Clean cutting blade for hard and soft
woods, plywood, blockboard,
plastic < 30mm.
10 U101B

H.C.S ground and tapered
thickness 1.3mm
(75mm) 3" KW03-1311 Splinter-free cutting (down cutting teeth)
in hard and soft woods, plywood,
laminated chipboard, plastic < 30mm.
6 U101D

H.C.S ground and tapered
thickness 1.3mm
(82mm) 3" KW03-1312 Clean parallel cuts in hard wood ,
softwood, blockboard, plywood,
chipboard, plastic < 60mm.
8.5 U301CD

H.C.S ground and tapered
thickness 1.3mm
(75mm) 3" KW03-0311 Reverse teeth for carved cut hardwood,
softwood, chipboard catting < 60mm.
7 U244DR

Tungsten carbide grit coated
(54mm) 2" KW03-1401 Coarse filing effect in abrasive materials
< 15mm.
Grit30 U30RIFF
